| Product Description: | |||||||
| ■Tinned ,annealed,stranded or solid copper conductor. | |||||||
| ■XL-PE insulation. | |||||||
| ■Rated temperature:105℃.Rated voltage:300volts | |||||||
| ■Uniform thickness of wire to ensure easy stripping and cutting. | |||||||
| ■Passes UL VW-1&CUL FT1/FT2 vertical flamt test | |||||||
| or horizontal flame test. | |||||||
| ■Executive Standard:UL758 UL1581 CSA22.2. | |||||||
| 说明： | |||||||
| ■导体使用单股或绞线裸铜或镀锡铜 | |||||||
| ■无卤照射环保PE绝缘 | |||||||
| ■额定温度：105℃额定电压：300Volts | |||||||
| ■使用标准厚度，易剥，截断容易。 | |||||||
| ■可通过ULVW-1及CUL FT1/FT2， | |||||||
| 垂直燃烧测试或水平燃烧测试。 | |||||||
| ■执行标准:UL758 UL1581 CSA22.2. | |||||||
| APPlications: | |||||||
| ■They are with the inner fixed wires for home | |||||||
| appliance,headlamp,mechanical etc. | |||||||
| 应用： | |||||||
| ■适用于多种家用电器、照明灯具、电子设备等引出连接线 | |||||||
| UL Style &CSA Type |
Conductor | Insulation Thickness |
Overall Diameter 完成外径 |
Stand Put-up | Conductor Resistance at 20℃ |
||
| AWG | No/mm | mm | Ft/coil | M/Coil | Ω/KM | ||
| UL3385 （Stranded) |
32 | 7/0.08 | 0.41 | 1.00 | 2000 | 610 | 586.00 |
| 30 | 7/0.10 | 1.10 | 381.00 | ||||
| 28 | 7/0.127 | 1.20 | 239.00 | ||||
| 26 | 7/0.16 | 1.30 | 150.00 | ||||
| 24 | 11/0.16 | 1.40 | 94.20 | ||||
| 22 | 17/0.16 | 1.60 | 59.40 | ||||
| 20 | 21/0.178 | 1.80 | 36.70 | ||||
| 18 | 34/0.178 | 2.10 | 23.20 | ||||
| 16 | 26/0.25 | 2.40 | 14.60 | ||||
| 14 | 21/0.178 | 2.80 | 8.96 | ||||
| 12 | 34/0.178 | 3.40 | 1000 | 305 | 5.64 | ||
| 10 | 26/0.25 | 4.00 | 3.55 | ||||
| UL3385 （Top-coated) |
28 | 7/0.127 | 1.20 | 2000 | 610 | 239.00 | |
| 26 | 7/0.16 | 1.30 | 150.00 | ||||
| 24 | 7/0.20 | 1.40 | 94.20 | ||||
| 22 | 7/0.25 | 1.60 | 59.40 | ||||
| UL3385 （Solid) |
28 | 1/0.32 | 1.10 | 239.00 | |||
| 26 | 1/0.404 | 1.20 | 150.00 | ||||
| 24 | 1/0.511 | 1.30 | 94.20 | ||||
| 22 | 1/0.643 | 1.40 | 59.40 | ||||
| 20 | 1/0.813 | 1.60 | 36.70 | ||||
| 18 | 1/1.024 | 1.80 | 23.20 | ||||
| 以上数据仅供参考，不作为正式的设计依据，产品规格以双方确认的规格书承认为准！最终解释权归东莞市扬大电子科技有限公司所有！ |
|||||||
